Rohde & Schwarz Digital 2 channel oscilloscope, 50MHz bandwidth (upgradable to 300MHz), sample rate up to 2GSa/s, 1MPts/channel, vert. 1mv to 10V/div, hor. 12 div, 6.5" VGA TFT, Ethernet/USB, USB flash drive connector, 2x R&S®RT-ZP03
The R&S®RTM3052 (part number 1335.7500.02) is a digital oscilloscope featuring 2 channels and a bandwidth of 50 MHz, which is upgradable to 300 MHz via software options. It offers a maximum real-time sample rate of 2 GSa/s and a memory depth of 1 Mpts per channel. The vertical sensitivity ranges from 1 mV/div to 10 V/div, and the horizontal display provides 12 divisions. The oscilloscope is equipped with a 6.5-inch VGA TFT color display for clear signal visualization. Connectivity options include Ethernet and USB interfaces, as well as a USB flash drive connector for data storage. The instrument is supplied with two R&S®RT-ZP03 passive probes. The R&S®RTM3052 is designed for precise signal analysis in laboratory and development environments.
